Ford - Diesel Power Stroke
Installation Instructions
Part Number: 150-2504
Application: FORD 6.7L POWERSTROKE DIESEL
Harmonic Balancer Bolt - Installation
[1]
Please check the part-number(s) for your
application against the part-number(s) listed on
the instruction sheet.
[2]
Clean and inspect all hardware prior to
installation. Look for obvious defects or shipping
damages, plus proper fit, length and dimension.
[3]
To ensure proper thread engagement and
accurate torque readings, clean the threads in
the end of the crankshaft. Chase if necessary
with a Thread Chaser or Tap.
[4]
Lubricate the threads of the bolts, the underhead
of the bolts and the front face of the balancer
(where the washers contact the balancer) with
ARP ULTRA-TORQUE FASTENER ASSEMBLY
LUBRICANT Install the washers onto the bolts
with the chamfered side facing the bolt head
then install the bolts hand tight.
[5]
Tighten the balancer bolts to 90 ft-lbs (122.0 Nm) using
ARP ULTRA TORQUE FASTENER ASSEMBLY
LUBRICANT.
If you have any questions or need additional information
please contact us at (805) 339-2200 or by FAX at (805)
650-0742.
