Xtreme Performance - 200mm Sprung Ceramic Twin Plate Clutch Kit Incl Flywheel 1200Nm IS 200 200 (GXE10)

KLX20520-2B
Xtreme Performance - 200mm Sprung Ceramic Twin Plate Clutch Kit Incl Flywheel 1200Nm IS 200 200 (GXE10)
KLX20520-2B
Xtreme Performance - 200mm Sprung Ceramic Twin Plate Clutch Kit Incl Flywheel 1200Nm IS 200 200 (GXE10)
€1.940,25
Price excluding VAT: €1.603,51
Our stock:
0 Items
Item No.:
KLX20520-2B
Xtreme Clutch

Xtreme Performance - 200mm Sprung Ceramic Twin Plate Clutch Kit Incl Flywheel 1200Nm IS 200 200 (GXE10)

Out of Stock at Supplier Neem contact op voor montage, Delivery time: Out of stock at supplier, delivery time unknown (Stock indication is updated weekly. This status is an indication.)
Xtreme Motorsport 200mm twin plate
The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality.

The 200mm Race Clutch Kits consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC).

Product Features:

  • Torque capacity 1200Nm
  • Kit contains everything you need for a successful installation + accessories
  • High torque sprung driven discs (common hub)
  • Push type billet alloy cover
  • 4140 Chromoly pressure & intermediate plates
  • Hardened steel wear posts
  • Low inertia
  • Serviceable components
  • SFI certified design
Clamping Force 1000kg
Torque Rating 1200Nm
Bearing Contact Diameter 44-52mm
Bearing Load (@ 48mm) 218kg
Release Travel Required 6mm
Assembly Mass (without flywheel) 7.4kg
Disc Set Static Mass 2.15kg
Friction Thickness New 7mm (0.275")
Friction Thickness Worn 6.48mm (0.255")

Xtreme Motorsport

Clutch Disc Diameter (mm): 200

Clutch Disc Spline Count: 21

Clutch Disc Spline Diameter (mm): 29.8

Torque (Nm): 1200

Flywheel Step: +2.2mm

Design: Twin Plate

Stage: Multiplate - track use only

Tech Bulletins:

Clamp Load:

Recommended for: Motorsport

Ring Gear Tooth count:

Additional information:

Fits:

- LEXUS/IS 200/200 (GXE10)/1999.04-2005.07/1G-FE 1988 Petrol 114 kW 155 BHP (1999.04 - 2005.07) ,
