Xtreme Performance - 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel LANCER EVO IV (CN9A)

Name: Xtreme Performance - 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel LANCER EVO IV (CN9A)
Brand: Xtreme Clutch
Price: 2116.30 EUR
Availability: InStock

€2.116,30

(Price excluding VAT): €1.749,01

Stock:

0 Items

Item No.:

KMI18522-3E

SKU

Xtreme Performance - 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel LANCER EVO IV (CN9A)

More Xtreme Clutch | More Clutch and flywheel

-3E

The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.

??	Ø184mm Light Diaphragm (2.6mm)	Ø184mm Heavy Diaphragm (2.8mm)
Clamping Force	950kg	1080kg
Torque Rating	1600Nm	1820Nm
Bearing Contact Diameter	44-52mm	44-52mm
Bearing Load (@ 48mm)	210kg	260kg
Release Travel Required	5mm	5mm
Assembly Mass (without flywheel)	4.75kg	4.75kg
Disc Set Static Mass	1.2kg
Friction Thickness New	2.6mm (0.103")	2.6mm (0.103")
Friction Thickness Worn	2.36mm (0.093")	2.36mm (0.093")

Product Features:

Push type billet alloy cover
4140 Chromoly pressure plate
Hardened steel wear posts
High and low ratio pressure plate options
Low inertia
Serviceable components
SFI certified design

Xtreme Motorsport

Clutch Disc Diameter (mm): 184

Clutch Disc Spline Count: 23

Clutch Disc Spline Diameter (mm): 26

Torque (Nm): 1830

Flywheel Step: +2.5mm

Design: Triple Plate

Stage: Multiplate - track use only

Tech Bulletins:

Clamp Load:

Recommended for: Motorsport

Ring Gear Tooth count:

Additional information:

Fits:

- MITSUBISHI/LANCER/EVO IV (CN9A)/1996.08-1997.12/4G63 Turbo 1997 Petrol 206 kW 280 BHP (1996.08 - 1997.12) ,

- MITSUBISHI/LANCER/EVO V - RS450 Ralliart (CP9A)/1998.01-1998.06/4G63 Turbo 1997 Petrol 336 kW 456 BHP (1998.01 - 1998.06) ,

- MITSUBISHI/LANCER/EVO V (CP9A. CT9A)/1998.01-1998.12/4G63 Turbo 1997 Petrol 206 kW 280 BHP (1998.01 - 1998.12) ,

- MITSUBISHI/LANCER/EVO VI (CP9A)/1999.01-2001.02/4G63 Turbo 1997 Petrol 207 kW 281 BHP (1999.01 - 2001.02) ,

- MITSUBISHI/LANCER/EVO IX - FQ-300 (CT9A)/2005.06-2006.12/4G63 Turbo 1997 Petrol 227 kW 309 BHP (2005.06 - 2006.12) ,

- MITSUBISHI/LANCER/EVO IX - FQ-340 (CT9A)/2005.06-2007.12/4G63 Turbo 1997 Petrol 257 kW 350 BHP (2005.06 - 2007.12) ,

- MITSUBISHI/LANCER/EVO IX - FQ-360 (CT9A)/2006.07-2007.12/4G63 Turbo 1997 Petrol 273 kW 371 BHP (2006.07 - 2007.12) ,

- MITSUBISHI/LANCER/EVO IX (CT9A)/2005.01-2007.09/4G63 Turbo 1997 Petrol 206 kW 280 BHP (2005.01 - 2007.09) ,

- MITSUBISHI/LANCER/EVO IX (CT9A)/2005.08-2006.09/4G63 Turbo 1997 Petrol 213 kW 290 BHP (2005.08 - 2006.09) ,

- MITSUBISHI/LANCER/EVO VII (CT9A)/2001.01-2003.01/4G63 Turbo 1997 Petrol 200 kW 272 BHP (2001.01 - 2003.01) ,

- MITSUBISHI/LANCER/EVO VII (CT9A)/2001.01-2003.01/4G63 Turbo 1997 Petrol 206 kW 280 BHP (2001.01 - 2003.01) ,

- MITSUBISHI/LANCER/EVO VIII - 260 (CT9A)/2004.03-2005.07/4G63 Turbo 1997 Petrol 195 kW 265 BHP (2004.03 - 2005.07) ,

- MITSUBISHI/LANCER/EVO VIII - FQ-300 (CT9A)/2003.04-2004.04/4G63 Turbo 1997 Petrol 225 kW 305 BHP (2003.04 - 2004.04) ,

- MITSUBISHI/LANCER/EVO VIII - FQ-300 (CT9A)/2003.04-2004.04/4G63 Turbo 1997 Petrol 227 kW 309 BHP (2003.04 - 2004.04) ,

- MITSUBISHI/LANCER/EVO VIII - FQ-320 (CT9A)/2004.04-2006.08/4G63 Turbo 1997 Petrol 243 kW 331 BHP (2004.04 - 2006.08) ,

- MITSUBISHI/LANCER/EVO VIII - FQ-330 (CT9A)/2003.10-2006.08/4G63 Turbo 1997 Petrol 246 kW 335 BHP (2003.10 - 2006.08) ,

- MITSUBISHI/LANCER/EVO VIII - FQ-340 (CT9A)/2004.04-2005.03/4G63 Turbo 1997 Petrol 255 kW 347 BHP (2004.04 - 2005.03) ,

- MITSUBISHI/LANCER/EVO VIII - FQ-400 (CT9A)/2004.10-2006.08/4G63 Turbo 1997 Petrol 302 kW 411 BHP (2004.10 - 2006.08) ,

- MITSUBISHI/LANCER/EVO VIII (CT9A)/2003.04-2005.03/4G63 Turbo 1997 Petrol 206 kW 280 BHP (2003.04 - 2005.03) ,
